Jumper Description

The SMARC/SL Carrier has a single jumper blocks for Carrier Reset and SATA Control.
J1A Jumper – SMARC/SL Carrier Reset
Function Carrier Reset
J1A
Location
Pinout
Position Description
ON
OFF
J1B Jumper – Ext SATA/mSATA Selection
Function External SATA/mSATA Selection
J1B
Location
Pinout
Position Description
ON
OFF
Switch Description
The SMARC/SL Carrier also has a single DIP Switch block for various on-board control.
S1 DIP Switch – Carrier Control
Function Boot Selection and Client USB
S1
Location
Pinout
Switch Description
A
B
C
D
E
F
Document: CTIM-00439
Revision: 0.00
ES France - Mobilité & Systèmes Embarqués
127 rue de Buzenval BP 26 - 92380 Garches
Place SMARC/SL Carrier into Reset
Normal Operation
Mini-PCIe Slot, SATA External Plug
mSATA Slot
BOOT_SEL0#
BOOT_SEL1#
BOOT_SEL2#
Client USB VBUS
Client USB OTG ID
Client USB Power
