INTRODUCTION

Connect Tech's Orbitty Carrier for
TX2/TX2i Solution to the market. Designed to match the NVIDIA® Jetson™ TX2 or TX2i module form
factor, the Orbitty's design includes Gigabit Ethernet, HDMI Video, USB 3.0, USB 2.0 (w/ OTG
functionality), 2 x UART ports and 4-bits of GPIO.

Product Features and Specifications

Module Compatibility
Mechanical Dimensions
Video Output
Ethernet
USB
Audio Output
UART
GPIO
SD Card
Video Inputs
I2C
Misc Interfaces
Document: CTIM-00471
Revision: 0.14
NVIDIA® Jetson™ TX2/TX2i
Specifications
NVIDIA Jetson TX2 or TX2i
Datasheet Downloads: Module Datasheet - SoC Datasheet
X/Y Footprint: 87mm x 50mm
- Tallest Component Height: 13.42mm (From Top PCB Surface of
Orbitty)
-
Total Stack Height: 30.18mm (Orbitty + TX2/TX2i/TX1 Module +
TX2/TX1 Flat Heatplate)
3D STEP Model: Download Here
1x HDMI 2.0 (Supports up to HDMI 2.0 UHD 4K [2160p] at 60Hz)
1x Gigabit Ethernet
10/100/1000 BASE-T
1x USB 3.0 (5Gbps, 1A Maximum Current Sourcing)
1x USB 2.0 (w/ OTG functionality)
HDMI Integrated
2x 3.3V UART Ports
TX/RX lines only
4-bits GPIO
- 3.3V CMOS Level
- Configurable as inputs or outputs
1x microSD Card Slot
- 4-bit Data
- Support for SD 4.0 Specification without UHS-II
Video Inputs can be accessed through any of the of the following interfaces:
- USB 3.0 / 2.0
- Gigabit Ethernet
1x I2C (Master Controller)
- Pullup Level: 1k ohm
- Operation Speeds: 100kbit/s, 400kbit/s, 1Mbit/s, 3.4Mbit/s
User Power Output Pins: +3.3V and +5V
Fan Connection: 4-pin, +5V, PWM Capability
On-board and External Button Interfaces: Reset, Power, Recovery
Page 7 of 31
Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
www.connecttech.com
brings a low-cost deployable Jetson™
