System; Camera Connector - Connect Tech SMARC/SL User Manual

System

The System header can be used to connect the power button, reset button, and suspend state required to
monitor the module performance or state.
Function System Connector
P10
Location
Type FCI MiniTek Double Row 5 x 2
P/N 98414-G06-10LF
10073599-010LF
Mating
Cable CBG134
Pinout
Pin Description
1 PWR_BTN#
3 RST_BTN#
5 BATLOW#
7 WAKE#
9 SUS_S3#

Camera Connector

Function MIPI 2-Lane Serial Camera Interface Connector
P11
Location
Type Hirose Low Profile Board to Cable Connector
P/N DF20G-20DP-1V(56)
Mating DF20A-20DS
CBG185
Cable
Pinout
Pin Description
1 +V_CAM
3
5
7 CAM0_PWR#
9 CAM0_RST#
11
13 CAM_I2C_CLK
15 CAM_I2C_DATA
17
19 CAM_MSTR_CLK
Note [1]: +V_CAM is a +3.3V Rail, However this can be modified upon request
