Detailed Feature Description

In SMARC Systems, the processor, chipset, and power control are all implemented on the SMARC Module.
This connects to the SMARC Carrier via a MXM 3.0 Style Connector.

SMARC

The processor and chipset are implemented on the SMARC Module, which connects to the SMARC/SL
Carrier Board via a MXM 3.0 fine pitch connector.
Function SMARC Module Interface
U10
Location
Type JAE Electronics MXM 3.0 Connector
Carrier MM70-314-310B1-2-R300
Connector Manufacturer: JAE Electronics
P/N
Refer to SMARC Hardware Specification V1.1
Pinout
