Appendix B: Dimensions

Table B-1 and Figure B-1 indicate the product dimensions. All dimensions shown in
inches (centimeters).
Width
4'
6'
C
9.5
D
8.0
A B
48.5 54.3
(123.2) (137.9)
72.5 78.3
(184.2) (198.9)
10.1 I.D.
O
A
B
Table B-1
C
17.2 22.5
(43.7) (57.2)
28.2 22.5
(71.6) (57.2)
Power Cord Inlet
61.6
83
D
Figure B-1
72.7
25.7
25.0
17.6
32.0
