condensation occur under the work surface. Simply snap in the supplied press-fit
elbow to the drain valve shown in Figure 4-9. Follow the diagram to finish the
installation.
Quick-Connect
Elbow Fitting
Circulator
(User-
Supplied)
Circulator Tubing
and Insulation
Figure 4-9
Optional
Drain Line
Temp-Zone
34
Prop
Rod
Press-fit
Elbow
Drain Valve
