Display Sleep Mode; Keypad - Labconco Cell Logic+ B2 User Manual

Display Sleep Mode

The LCD display will enter sleep mode when the blower is off (Figure 6-2). If the blower
is not turned on, and no keys are pressed on the keypad, after 5 minutes the screen will
automatically turn off to relax the LCD display, which extends its life. When the display
transitions from sleep mode to off, the screen will appear black. Any key press will
wake the screen and return to the Home Screen.

Keypad

The Keypad button functions are explained in detail in
Type B2, under the subsection Keypad. A summary description is provided here with
Figure 6-3.
[BLOWER]
[LIGHT]
[OUTLET]
[UV LIGHT]
[TIMER]
[OK/MUTE]
[MENU]
[UP]
[DOWN]
43
Figure 6-2
Section 7: Using Your Cell Logic+
Figure 6-3
