Instruction Functions
Instruction Symbol/Operand
Mnemonic
Code
TENTH-MS
TIMER (CJ1-H-R
only)
TIMU
541
(BCD) N: Timer number
S: Set value
TIMUX
TIMUX(556)
556
(BCD)
N: Timer number
S: Set value
HUNDREDTH-MS
TMUH(554)
TIMER (CJ1-H-R
only)
TMUH
554
N: Timer number
(BCD)
S: Set value
TMUHX
TMUHX(557)
557
(BCD)
N: Timer number
S: Set value
TIMU(541)/TIMUX(556) operates an decrementing timer with units of
TIMU(541)
0.1-s. The setting range for the set value (SV) is 0 to 0.999 s for BCD
and 0 to 6,553.5 s for binary (decimal or hexadecimal).
N
S
Timer input
Timer PV
Completion
N
Flag
S
Timer Input Turns OFF before Completion Flag Turns ON
Timer input
Timer PV
Completion
Flag
Note: The timer's present value cannot be accessed for a TENTH-MS
TIMER instruction.
TMUH(554)/TMUHX(557) operates an decrementing timer with units of
0.01-s. The setting range for the set value (SV) is 0 to 0.0999 s for BCD
and 0 to 0.65535 s for binary (decimal or hexadecimal).
N
S
ON
Timer input
OFF
Timer PV
Completion
ON
N
OFF
Flag
S
Timer Input Turns OFF before Completion Flag Turns ON
ON
Timer input
OFF
Timer PV
Completion
ON
Flag
OFF
Note: The timer's present value cannot be accessed for a HUN-
DREDTH-MS TIMER instruction.
Function
ON
OFF
SV
0
ON
OFF
ON
OFF
SV
0
ON
OFF
SV
0
SV
0
Section 2-2
Location Page
Execution
condition
Output 256
Required
Output 259
Required
