Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual page 121

Instruction Functions
Instruction Symbol/Operand
Mnemonic
Code
SCALING 2
SCL2(486)
SCL2
@SCL2
486
S: Source word
P1: 1st parameter
word
R: Result word
Converts signed binary data into signed BCD data according to the
specified linear function. An offset can be input in defining the linear
function.
S
P1
Positive Offset
R (signed BCD)
R
Offset
S (signed binary)
P1
Offset
Y
P1 + 1
X
P1 + 2
Function
Negative Offset
R (signed BCD)
Y
X
Offset
Offset of 0000
(Signed binary)
R (signed BCD)
(Signed binary)
(Signed BCD)
Offset = 0000 hex
Section 2-2
Location
Execution
condition
Output
Required
Y
X
S (signed
binary)
Y
X
S (signed
binary)
Page
800
81
