Timer and Counter Instructions
3-6-1

HUNDRED-MS TIMER: TIM/TIMX(550)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
2. It is not possible to read the timer PVs of TIMU(541), TIMUX(556),
TMUH(544), and TMUHX(557).
TIM or TIMX(550) operates a decrementing timer with units of 0.1-s. The set-
ting range for the set value (SV) is 0 to 999.9 s for TIM and 0 to 6,553.5 s for
TIMX(550). The timer accuracy is 0 to 0.01 s.
Note The timer accuracy for CS1D CPU Units is 10 ms + the cycle time. The timer
accuracy for unit version 4.1 of the CJ1-H-R CPU Units is 0.1 to 0 s. The
timer accuracy for other unit versions of the CJ1-H-R CPU Units is 0 to 0.01 s.
PV
refresh
method
BCD
Binary
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
Not allowed
N: Timer Number
The timer number must be between 0000 and 4095 (decimal).
S: Set Value
The set value must be between #0000 and 9999 (BCD).
(If the set value is set to #0000, the Completion Flag will be turned ON when
TIM/TIMX(550) is executed.)
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
Symbol
TIM
N
N: Timer number
S
S: Set value
TIMX(550)
N
N: Timer number
S
S: Set value
Step program areas
OK
N
---
---
---
---
0000 to 4095 (decimal)
---
---
Section 3-6
Operands
N: 0000 to 4095 (decimal)
S: #0000 to #9999 (BCD)
N: 00000 to 4095 (decimal)
S: &0 to &65535 (decimal)
#0000 to #FFFF (hex)
TIM/TIMX(550)
Not supported.
Not supported.
Subroutines Interrupt tasks
OK Not allowed
S
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
245
