Data Control Instructions

3-18-6 TIME-PROPORTIONAL OUTPUT: TPO(685)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Inputs the duty ratio or manipulated variable from the specified word, converts
the duty ratio to a time-proportional output based on the specified parameters,
and outputs the result from the specified output.
This instruction is supported only by CS/CJ-series CPU Unit Ver. 2.0 or later.
TPO
S S: Input word
C C: First parameter word
R: Pulse output bit
R
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported.
Immediate Refreshing Specification
Block program areas
Not allowed OK
S: Input Word
Specifies the input word containing the input duty ratio or manipulated vari-
able. Bits 04 to 07 of C specify the input type, i.e., whether the input word con-
tains an input duty ratio or manipulated variable. (Set these bits to 0 hex to
specify a input duty ratio or to 1 hex to specify a manipulated variable.)
• Input duty ratio: 0000 to 2710 hex (0.00% to 100.00%)
• Input manipulated variable (See note.): 0000 to FFFF hex (0 to 65,535
max.) (Bits 00 to 03 of C specify the manipulated variable range, i.e., the
number of valid bits in the manipulated variable. Specify the same number
of bits as specified for the output range setting in PID(190).)
Note If S is a manipulated variable, specify the word containing the manip-
ulated variable output from a PID(190) or PIDAT(191) instruction.
C to C+6: Parameters
The following diagram shows the locations of the parameter data. For details
on the parameters, refer to Parameter Settings in this section.
Step program areas Subroutines
OK
Section 3-18
TPO(685)
Not supported.
Not supported.
Interrupt tasks
OK
787
