Symbol Math Instructions - Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 Reference Manual

Symbol Math Instructions

3-11 Symbol Math Instructions
This section describes the Symbol Math Instructions, which perform arith-
metic operations on BCD or binary data.
Instruction
SIGNED BINARY ADD WITH-
OUT CARRY
DOUBLE SIGNED BINARY
ADD WITHOUT CARRY
SIGNED BINARY ADD WITH
CARRY
DOUBLE SIGNED BINARY
ADD WITH CARRY
BCD ADD WITHOUT CARRY
DOUBLE BCD ADD WITHOUT
CARRY
BCD ADD WITH CARRY
DOUBLE BCD ADD WITH
CARRY
SIGNED BINARY SUBTRACT
WITHOUT CARRY
DOUBLE SIGNED BINARY
SUBTRACT WITHOUT CARRY
SIGNED BINARY SUBTRACT
WITH CARRY
DOUBLE SIGNED BINARY
SUBTRACT WITH CARRY
BCD SUBTRACT WITHOUT
CARRY
DOUBLE BCD SUBTRACT
WITHOUT CARRY
BCD SUBTRACT WITH
CARRY
DOUBLE BCD SUBTRACT
WITH CARRY
SIGNED BINARY MULTIPLY
DOUBLE SIGNED BINARY
MULTIPLY
UNSIGNED BINARY MULTI-
PLY
DOUBLE UNSIGNED BINARY
MULTIPLY
BCD MULTIPLY
DOUBLE BCD MULTIPLY
SIGNED BINARY DIVIDE
DOUBLE SIGNED BINARY
DIVIDE
UNSIGNED BINARY DIVIDE
DOUBLE UNSIGNED BINARY
DIVIDE
BCD DIVIDE
DOUBLE BCD DIVIDE
Mnemonic Function code
+ 400
+L 401
+C 402
+CL 403
+B 404
+BL 405
+BC 406
+BCL 407
– 410
–L 411
–C 412
–CL 413
–B 414
–BL 415
–BC 416
–BCL 417
* 420
*L 421
*U 422
*UL 423
*B 424
*BL 425
/ 430
/L 431
/U 432
/UL 433
/B 434
/BL 435
Section 3-11
Page
426
428
430
432
434
435
437
439
440
442
446
448
451
452
456
457
459
461
463
465
467
469
471
473
475
477
479
481
425
