Serial Communications Instructions
Related Flags and Words
988
The following PLC Setup settings and Auxiliary Area flag can be used as
required when executing TXD(236).
PLC Setup Settings for CPU Unit's RS-232C Port
Programming
Console address
Word Bit
162 0 to 15 No-protocol Mode Send
Delay
164 8 to 15 No-protocol Mode Start Code 00 to FF hex
0 to 7 No-protocol Mode End Code
165 12 No-protocol Mode Start Code
Specifier
8 and 9 No-protocol Mode End Code
Specifier
0 to 7 No-protocol Mode Number of
bytes of Data
DM Setup Area Settings for Serial Communication Board's Ports
Setup Area word Bit
Port 1 Port 2
D32002 D32012 15
0 to 14
D32004 D32014 8 to 15
0 to 7
D32005 D32015 12 to 15 No-protocol Mode Start
8 to 11
Auxiliary Area
Send Ready Flags
Port
CPU Bus Unit's built-in RS-232C Port A39205
Serial Communications Board port 1
Serial Communications Board port 2
Inner Board Flags for Serial Communications Board (Ports 1 and 2)
Name
Inner Board Service Dis-
abled Flag
Name
0000 to 210F hex,
0 to 99,990 ms decimal (in 10-
ms units)
00 to FF hex
0: None
1: Use start code.
0: None
1: Use end code.
2: Use CR+LF.
00: 256 bytes
01 to FF: 1 to 255 bytes
Name
No-protocol Mode Send
Delay Specifier
No-protocol Mode Send
Delay Time
No-protocol Mode Start
Code
No-protocol Mode End
Code
Code Specifier
No-protocol Mode End
Code Specifier
Address
ON when data can be sent in
the no-protocol mode.
A35605
A35613
Address
A42404 ON when TXD(236) is executed for a
Serial Communications Board that
does not support no-protocol mode (a
Board without a version number).
Section 3-24
Settings
Settings
0: Default (0 ms)
1: Use delay in bits 1 to 14.
0000 to 7530 hex
0 to 300,000 ms decimal
(in 10-ms units)
00 to FF hex
00 to FF hex
0: None
1: Use start code.
0: None
1: Use end code.
2: Use CR+LF.
Contents
Contents
