Model Conversion Instructions (Unit Ver. 3.0 or Later)

3-35-2 SINGLE WORD DISTRIBUTE: DISTC(566)

Purpose
Ladder Symbol
Variations
Applicable Program Areas
Operands
Operand Specifications
1266
Transfers the source word to a destination word calculated by adding an offset
value to the base address.
DISTC(566)
S: Source word
S
Bs Bs: Destination base address
Of Of: Offset
Variations Executed Each Cycle for ON Condition
Executed Once for Upward Differentiation
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification
Block program areas
OK OK
Bs: Destination Base Address
Specifies the destination base address. The offset is added to this address to
calculate the destination word.
Of: Offset
• Data Distribution Operation (0000 to 7999 BCD)
This value is added to the base address to calculate the destination word.
The offset can be any value from 0000 to 7999 in BCD, but Bs and Bs+Of
must be in the same data area.
• Stack Push Operation (9000 to 9999 BCD)
When the leftmost digit of Of is 9, the rightmost 3 digits of Of specify the
number of words in the stack. The offset can be any value from 9000 to
9999 BCD.
Area
CIO Area
Work Area
Holding Bit Area
Auxiliary Bit Area
Timer Area
Counter Area
DM Area
EM Area without bank
Step program areas Subroutines
OK
15
Bs
to
to
Bs+Of
S
CIO 0000 to CIO 6143
W000 to W511
H000 to H511
A000 to A959 A448 to A959
T0000 to T4095
C0000 to C4095
D00000 to D32767
E00000 to E32767
Section 3-35
DISTC(566)
@DISTC(566)
Not supported
Interrupt tasks
OK
0
Bs Of
A000 to A959
