Block Programming Instructions
Examples

3-32-9 TEN-MS TIMER WAIT: TMHW(815) and TMHWX(817)

Purpose
Ladder Symbol
1212
When CIO 000000 is ON in the following example, "A" will be executed and
then execution of the rest of the block program "B" will wait until 7,000 counts
of CIO 000100.
Address
000200
000201
.
.
000210
.
.
000220
Program execution will flow from 2 to 3 to 4 and back to 2 during the 7,000
counts before "B" is executed, as shown in the following diagram.
Delays execution of the rest of the block program until the specified time has
elapsed. Execution will be continued from the next instruction after
TMHW(815)/TMHWX(817) when the timer times out.
PV Refresh Method: BCD
TMHW(815) N
SV
PV Refresh Method: Binary
TMHWX(817) N
SV
CIO 000100
0
counted.
Instruction
LD
BPRG
A
CNTW
B
BEND
1 4
2
N: Timer number
SV: Set value
N: Timer number
SV: Set value
Section 3-32
Updated
Updated
Counter counts out.
Operand
000000
0
.
.
0005
#7000
000100
.
.
---
3
