CS-series Instruction Execution Times and Number of Steps
4-1-6 Data Movement Instructions
Instruction Mnemonic
MOVE MOV
!MOV
DOUBLE MOVL
MOVE
MOVE NOT MVN
DOUBLE MVNL
MOVE NOT
MOVE BIT MOVB
MOVE DIGIT MOVD
MULTIPLE XFRB
BIT TRANS-
FER
BLOCK XFER
TRANSFER
BLOCK SET BSET
DATA XCHG
EXCHANGE
DOUBLE XCGL
DATA
EXCHANGE
SINGLE DIST
WORD DIS-
TRIBUTE
DATA COL- COLL
LECT
MOVE TO MOVR
REGISTER
MOVE TIMER/ MOVRW
COUNTER PV
TO REGIS-
TER
1290
Code Length
(steps)
(See note.)
021 3
021 7
498 3
022 3
499 3
082 4
083 4
062 4
070 4
071 4
073 3
562 3
080 4
081 4
560 3
561 3
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
ON execution time ( s)
CPU-6@H CPU-4@H CPU-6@
0.18 0.20 0.25
+21.38 +21.40 +42.36
+90.52 +90.52 +90.52
0.32 0.34 0.42
0.18 0.20 0.25
0.32 0.34 0.42
0.24 0.34 7.5
0.24 0.34 7.3
10.1 10.8 13.6
186.4 189.8 269.2
0.36 0.44 11.2
300.1 380.1 633.5
0.26 0.28 8.5
200.1 220.1 278.3
0.40 0.56 0.5
0.76 1.04 0.9
5.1 5.4 7.0
5.1 5.3 7.1
0.08 0.08 0.42
0.42 0.50 0.42
Section 4-1
Conditions
CPU-4@
0.29 ---
+42.36 Increase for CS
Series
+90.52 Increase for
C200H
0.50 ---
0.29 ---
0.50 ---
7.5 ---
7.3 ---
13.6 Transferring 1
bit
269.2 Transferring 255
bits
11.2 Transferring 1
word
633.5 Transferring
1,000 words
8.5 Setting 1 word
278.3 Setting 1,000
words
0.7 ---
1.3 ---
7.0 ---
7.1 ---
0.50 ---
0.50 ---
