MAIN MICROSCOPE
The objective lenses with focal lengths of 250mm, 300mm and
400mm are available for different working distances.
Also Variable working distance CMO like NuVar 7, NuVar 10 and
NuVar 20 also available on demand. For more details of NuVar
refer brochure.
The ergonomic 210 degree binocular tube is provided for the main
surgeon. The large tilt range allows work with minimum fatigue.
The standard equipment includes eyepieces with a magnification
factor of 10X (option:12.5X).
20. INSTRUCTIONS FOR USING THE MICROSCOPE
1. The objectives can be taken out by rotating in anti-clock wise
direction. It can be thread in by rotating in clockwise direction.
2. To install the eyepieces, insert in the eye tubes of observation
head.
3. To install the eyepieces, insert in the eye tubes of observation
head.
6182001-795 Prima Pro
Fig. 47
Fig. 48
