eVO 350
Slit Lamp
User Manual
Part No: 8126300-795
Issue 1.2
Printed on June,2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eVO 350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Labomed eVO 350

  • Page 1 350 Slit Lamp User Manual Part No: 8126300-795 Issue 1.2 Printed on June,2020...
  • Page 2 350 eVO 350 is a registered Trade Mark of Labotech Microscopes India Pvt. Ltd. Labomed is the registered Trade Mark of Labo America Inc. All other trade marks are property of their respective owners. The information contained in this document was accurate at the time of publication. Specification subject to change without notice.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings and Cautions Symbol Information Introduction Indications for Use Contraindications Setup Parts Identification eVO 350 Package Contents Accessories Unpacking & Installation Application of Input Power Disconnection of Input Power Instructions for Use Operation Slit Length Filter Dial Slit Rotation Cleaning, Disinfection &...
  • Page 4: Warnings And Cautions

    WARNING: THIS INSTRUMENT SHOULD BE USED IN STRICT ACCORDANCE WITH THE INSTRUCTIONS OUTLINES IN THIS USER’S GUIDE. THE SAFETY OF THE OPERATOR AND THE PERFORMANCE OF THE INSTRUMENT CANNOT BE GUARANTEED IF USED IN A MANNER NOT SPECIFIED BY LABOMED TECHNOLOGIES.
  • Page 5 EQUIPMENT. CAUTION: THIS INSTRUMENT IS NOT INTENDED TO BE CONNECTED TO EQUIPMENT OUTSIDE THE CONTROL OF LABOMED OR MUST BE TESTED TO AN APPLICABLE IEC OR ISO STANDARDS. CAUTION: CHIN REST PAPER-FOR SINGLE USE ONLY. REPLACE WITH EACH PATIENT. Issue 1.2...
  • Page 6: Symbol Information

    350 EXPLANATION OF SYMBOLS The following symbols appear on the instrument: Caution symbol indicating important operating and maintenance instructions that are included in this User’s Guide. Type B Applied Part Alternating Current Power Protective Earth Connection ON/OFF Manufacture LABOMED...
  • Page 7: Introduction

    INDICATIONS FOR USE The eVO 350 Slit Lamp is an AC-powered slit lamp biomicroscope that is intended for use in examining the anterior segment, from the corneal epithelium to the posterior capsule. It is used to aid in the diagno- sis of diseases or trauma, which affect the structural properties of the anterior segment of the eye.
  • Page 8: Setup

    350 SETUP eVO 350 PACKAGE CONTENTS PART IDENTIFICATION 1. eVO 350 Slit Lamp HL (8126300) 1. On/Off Switch 2. eVO 350 Slit Lamp LED (8126303) 2. Illumination level Control 3. User’s Guide (8126300-795) 3. Glide Plate 4. Joystick for horizontal and...
  • Page 9: Unpacking & Installation

    350 SETUP (continued) UNPACKING AND INSTALLATION 1. Open the outside shipping box and remove the three (3) inner boxes. 2. Remove the User’s Guide and follow it for Slit lamp installation. 3. Open the box marked as ‘’Platform Assembly’’...
  • Page 10 350 SETUP (continued) Accessories UNPACKING AND INSTALLATION (continued) Slit lamp Base 7. Open the box marked as ‘’Microscope Assembly’ ’. Remove the Microscope Assembly, Slit lamp Assembly, Power Supply and Accessories. Refer to Power Figure-5. Supply 8. Install the Slit Lamp Assembly onto the tracks of...
  • Page 11: Application Of Input Power

    350 SETUP (continued) UNPACKING AND INSTALLATION (continued) 15. Install the Microscope Assembly onto the top of the Arm by sliding it into position, making sure it is up against the stop. Then, tighten the Lock Knob located on the right side of the Microscope Assembly.
  • Page 12: Instructions For Use

    350 INSTRUCTIONS FOR USE OPERATION 1. Turn on the power using the On/Off switch located on the front of the Power Supply Assembly. Brightness can be Projected Slit adjusted by rotating the illumination level knob. NOTE: The maximum position is for intermittent use only.
  • Page 13: Slit Length

    350 INSTRUCTIONS FOR USE (continued) OPERATION (continued) 11. The slit width can be adjusted by rotating the Slit Magnification Width/Rotation Knob on either side of the instrument. Dial Refer to Figure-15. 12. The angle between the illumination system and the microscope can be varied between 0˚and 90˚...
  • Page 14: Cleaning, Disinfection & Maintenance

    350 CLEANING, DISINFECTION & MAINTENANCE WARNING: RISK OF ELECTRIC SHOCK. ALWAYS DISCONNECT THE POWER CORD FROM THE WALL AND THE INSTRUMENT BEFORE PERFORMING ANY OF THE FOLLOWING CARE AND MAINTENANCE PROCEDURES. EXTERNAL CLEANING Clean the external surfaces of this instrument using a clean, soft cloth moistened with a mild detergent solution of liquid dish soap (filtered below 5 microns).
  • Page 15: Changing The Halogen Bulb

    350 CHANGING THE HALOGEN BULB Retaining Bulb Holder WARNING: NEVER REMOVE A BULB THAT HAS spring RECENTLY BEEN IN USE AS IT WILL BE VERY HOT. WAIT UNTIL IT HAS COOLED AND USE GLOVES OR A Bulb THICK CLOTH WHEN HANDLING ANY HALOGEN BULB.
  • Page 16: Changing The Led

    350 CHANGING THE LED (For LED illumination only) WARNING: NEVER REMOVE A LED THAT HAS RECENTLY BEEN IN USE AS IT MAY BE VERY HOT. WAIT UNTIL IT IS COOLED. WARNING: NEVER TOUCH A LED WITH BARE HANDS AS FINGERPRINTS WILL SHORTEN THE LED LIFE.
  • Page 17: Fuse Replacement

    350 FUSE REPLACEMENT Replace the fuses in the Power Input Module with the Cut Out Notch fuses indicated in the Specifications section of this manual. Remove input power to the instrument. Press down on the top tab in the middle of the...
  • Page 18: Troubleshooting

    Bulb not installed properly. with bulb housing. The following is a checklist of items that need to be assessed in order to determine if the eVO 350 Slit Lamp requires servicing. • Check the outside of the Slit Lamp for any damage or missing components.
  • Page 19: Specifications

    350 SPECIFICATIONS Catalog Number 8126300-795 Physical Dimensions Size: Weight, unpacked: 23.0 lbs. (10.4 Kg) Height: 19.8 in. (50.2 cm) Weight, packed: 52 lbs (23.64 Kg) Width: 10.5 in. (26.7 cm) Depth: 14.0 in. (35.6 cm) Electrical voltage: 100-240 vAC...
  • Page 20: Disposal

    350 SPECIFICATIONS (continued) MOVEMENT RANGES Longitudinal (In/Out) 100mm Lateral (Left/Right) 107mm V e r t i c a l (Up/Down) 30mm Chin rest Range 80mm Table Dimensions 18 1/2" x 12 10/16" (465 mm x 316 mm) DISPOSAL This product does not generate any environmentally hazardous residues. At the end of its product life, follow your local laws and ordinances regarding the proper disposal of this equipment.
