WALL MOUNT INSTALLATION PROCEDURE (continued)
CONSTRUCTIONAL REQUIREMENTS FOR THE WALL MOUNT
1. The wall mount assembly must only be installed as recommended in this manual.
2. The construction specialist responsible must confirm in writing that the applicable regional and
local bodies & regulations have been complied and the points listed below are taken care. The
customer must keep this confirmation with his records on the wall mount. A copy of this document
must be provided to labomed representative dealer.
3. The wall on which wall mount is to be mounted must have the following load capacity:
Perpendicular force: minimum 1500 Nm
Also take into account any additional loads acting on the wall.
4. The wall mount must be aligned in a parallel position (max. deviation ±1˚).
NOTE:
If an existing wall mount is ever exchanged, never re-use the old anchors. New anchor holes must
be drilled. When calculating the effective strength of the new anchors, make sure to take into
account the weakening effect of the old holes in the wall.
On the basis of the above aspects, the person responsible for the building must decide on and take
responsibility for the most suitable method of anchoring.
