WALL MOUNT INSTALLATION PROCEDURE (continued)
CONTROL AND POWER SUPPLY OF THE SYSTEM
NOTE:
The maximum weight of the surgical microscope including accessories must not exceed 7kg and
the respective weight of our accessory equipment is specified in the price list.
The weight of the mount including the surgical microscope is as follow:
Wall mount kit
Surgical microscope
Total
Power Line
Fuse
Power Consumption
NOTE:
A socket with properly installed protective earth connection must be provided at the installation
site.
Potential equalization: Take the necessary actions in the building to include the instrument in the
protective measure of "potential equalization''.
NOTE:
The series 6181000 suspension systems including the components mentioned here comply safety
requirement with CE, MDD 92/42 EEC and IEC 60601-1-3.2.
Such activities as the installation of the flange and the installation of conduits and electrical lines
are the customer's responsibilities.
List of Contents: Wall Mount Kit
1.
Raval Plugs
2.
Washers
3.
Wall Mount
6182001-795
:
12 kg
:
20 kg
:
32 kg
: 3/1.5mm 2
: 4.0 Amp
: Max. 200W
: 06 Nos
: 06 Nos
: 01 Nos
Prima Pro
Issue 1.0
Printed on Jan, 2024
