CONTROL ELEMENTS (continued)
6. FILTER CHANGE LEVER
Refer Fig. 42 (L). Filter change Lever is located in left side of the
magnichanger housing. Use lever by pulling out to change the
filter and push back to main light.
7. BRAKES
Locks the stand from unwanted movement by pressing down the
two brakes provided on caster wheels. To unlock press upper
portion of brake. See (M) Fig. 43.
8. LED FEATURES
Single Chip White LED with over 2250 white lumen's. Lumen
maintenance of greater than 70% after 60000 Hrs. Environment
friendly ROHS Compliant. Typical spectrum is 400 - 700 nm.
6182001-795 Prima Pro
L
Fig. 42
M
Fig. 43
