CEILING MOUNT INSTALLATION (continued)
5d. Constructional requirements for the ceiling mount installation on concrete ceiling
1. The ceiling mount must be installed as recommended in this manual.
2. The construction specialist responsible must confirm in writing that the applicable regional and
local bodies & regulations have been complied and the points listed below are taken care. The
customer must keep this confirmation with his records. A copy of this document must be provided
to labomed representative dealer.
3. The roof on which ceiling mount is to be mounted must have the following load capacity:
Perpendicular force: minimum 1500 Nm.
Torque: Perpendicular to the Ceiling 1500 Nm minimum.
Also take into account any additional loads acting on the Ceiling and any other loads anchored
in the Ceiling.
4. The Master Plate should be installed at the time of Construction.
5. Minimum edge distance required on all sides is 16".
6. The ceiling plate must be aligned in a parallel position (max. deviation ±1˚).
Note:
1. If an existing ceiling mount is ever exchanged, never re-use the old anchors. New anchor holes
must be drilled. When calculating the effective strength of the new anchors, make sure to take
into account the weakening effect of the old holes in the ceiling.
2. On the basis of the above aspects, the person responsible for the building must decide on and take
responsibility for the most suitable method of anchoring.
