1. INTRODUCTION AND INTENDED USE
The LABOMED Prima is a surgical and diagnostic microscope which is adaptable for different surgical needs for
consistent visualization during all intra operative phases of dental surgeries by providing magnified view of the
surgical field without compromise to performance.
The microscope provides extremely high optical image quality, good depth of focus and wide field of view for precise
surgery. Illumination control, inbuilt tilt, adjustment of the observation head, helps to reduce the Surgeon's work
fatigue and allow comfortable use over long period.
Salient features of this Microscope are:
1. The observation head can easily be positioned with the help of a suspension arm.
2. An advanced 6-step magnification changer allows an optimal magnification for a particular surgery
from five different magnifications.
3. Cold light illumination with a high intensity 50 W LED lamp is provided in magnichanger for proper
illumination. The illumination is further adjustable up to its most suitable brightness using intensity
control knob suitably located at the suspension arm, and is easily approachable to the surgeon.
4. An effortless articulation system ABA (Automatic Balancing Arm) features an electromagnetic brake
system that enables the ultimate flexibility in manoeuvring the microscope's viewing angle and
position.
5. The Labomed NuVar CMO with variable working distance comes as standard and provide greater convenience
to user in achieving a comfortable working distance.
6. Dual iris Diaphragm allows greater depth of field particularly valuable for photography.
7. Rigid Star type base with castor wheels provides greater stability as well as mobility to the instrument.
INTENDED USE:
Prima Surgical Microscope is an AC powered device intended for use during diagnosis and Surgery to
provide a magnified view of surgical field. .
NOTE: The use of Prima Microscope is purely for intended use.
CONFIGURATIONS
Microscope
Prima Pro (Floor Stand)
Prima Pro (Wall Mount)
Prima Pro (Ceiling Mount)
6182001-795
Catalogue No.
6183601
6183602
6183603
