Trojan MULTIFUNTION SMITH MACHINE User Manual page 8

56. BEARING
(4 PCS)
61. SHORT METAL
CABLE TRAP (2 PCS)
66. 17 MM SPACER
(4 PCS)
71. BUTTERFLY CABLE
(1 PC)
76. M10 LARGE WASHER
(2 PCS)
81. CHAIN
(1 PC)
86. M6 WASHER
(13 PCS)
#21M05T035 Multifunction Smith Machine UM A4.indd 8
HARDWARE & TOOLS LIST
57. SWIVEL AXLE
(2 PCS)
62. LONG METAL 63. PLASTIC CABLE TRAP
CABLE TRAP (2 PCS)
67. HANDLE
(2 PCS)
72. LOW CABLE
(1 PC)
77. M10 X 20MM
BUTTON BOLT (4 PCS)
82. M4 X 19 MM SELF-TAPPING 83. M10 X 65 MM CARRIAGE
SCREW (16 PCS)
87. M6 X 70 MM SCREW 88. M10 X 63 MM BOLT
(6 PCS)
58. 90 MM PULLEY 59. 115 MM PULLEY
(20 PCS)
64. CARRIAGE GUIDE
(5 PCS)
68. SNAP RING 69. CABLE CLIP
(2 PCS)
73. HIGH CABLE 74. PULLEY PLATE
(1 PC)
78. M8 LOCKNUT 79. M10 LOCKNUT
(8 PCS)
84. M10 WASHER (64 PCS)
BOLT (10 PCS)
89. M10 X 90 MM BOLT
(2 PCS)
8
60. V-PULLEY
(3 PCS) (2 PCS)
65. LAT BAR
(2 PCS) (1 PC)
70. 50 MM X 50 MM CAP
(2 PCS) (2 PCS)
75. 6 MM SPACER
(2 PCS) (6 PCS)
80. 25 MM X 2 MM
(74 PCS) ROUND CAP (2 PCS)
85. M8 X 20 MM SHOULDER
BOLT (2 PCS)
90. M10 X 68 MM BOLT
(7 PCS) (10 PCS)
