Parts List - Trojan MULTIFUNTION SMITH MACHINE User Manual

No. Description
1 Base
2 Centre Base
3 Left Upright
4 Right Upright
5 Weight Bar Guide
6 Left Support
7 Right Support
8 Backrest Upright
9 Foot Plate
10 Left Arm
11 Right Arm
12 Arm Frame
13 Side Top Frame
14 Centre Top Frame
15 Support Frame
16 Top Frame
17 Weight Bar
18 Locking Bar
19 Right Carriage
20 Left Carriage
21 Screw (M8 x 20 mm)
22 Weight Bar Adapter
23 Weight Bar Bushing
24 Left Spotter
25 Right Spotter
26 Spotter Bushing
27 Carriage Bumper
28 Carriage Bushing
29 Upright Backrest
30 Arm Pad
31 Arm Bushing
32 Swivel Arm
33 Guide Cap
34 Screw (M6 x 20mm)
35 Barbell Rest
#21M05T035 Multifunction Smith Machine UM A4.indd 11

PARTS LIST

Qty No. Description
2 36 Barbell Spotter
1 37 Weight Bumper
1 38 Round Cap (48 mm)
1 39 Full Guard
2 40 Half Guard
1 41 Weight Carriage
1 42 Carriage Bushing
1 43 Ankle Strap
1 44 Spacer (50 mm)
1 45 Spacer (24 mm)
1 46 Double U-bracket
1 47 U-bracket
2 48 Handgrip
1 49 Cap (50 mm x 75 mm)
2 50 Stabiliser Foot
1 51 Large Base Foot
1 52 Cable Stop
1 53 Clip
1 54 Long Cable
1 55 Spacer (25 mm)
1 56 Bearing
2 57 Swivel Axle
2 58 Pulley (90 mm)
1 59 Pulley (115 mm)
1 60 V-pulley
8 61 Short Metal Cable Trap
6 62 Long Metal Cable Trap
4 63 Plastic Cable Trap
1 64 Carriage Guide
2 65 Lat Bar
4 66 Spacer (17 mm)
2 67 Handle
2 68 Snap Ring
4 69 Cable Clip
2 70 Cap (50 mm x 50 mm)
11
Qty
2
4
4
4
22
1
2
1
1
2
1
1
2
7
4
2
4
4
1
14
4
2
20
3
2
2
2
5
2
1
4
2
2
2
2
