Trojan MULTIFUNTION SMITH MACHINE User Manual page 7

21. M8 X 20 MM SCREW
(2 PCS)
26. SPOTTER BUSHING
(8 PCS)
31. ARM BUSHING
(4 PCS)
36. BARBELL SPOTTER
(2 PCS)
41. WEIGHT CARRIAGE
(1 PC)
46. DOUBLE U-BRACKET
(1 PC)
51. LARGE BASE FOOT
(2 PCS)
#21M05T035 Multifunction Smith Machine UM A4.indd 7
HARDWARE & TOOLS LIST
22. WEIGHT BAR ADAPTER 23. WEIGHT BAR BUSHING
(2 PCS)
27. CARRIAGE BUMPER 28. CARRIAGE BUSHING
(6 PCS)
32. SWIVEL ARM
(2 PCS)
37. WEIGHT BUMPER 38. 48 MM ROUND CAP
(4 PCS)
42. CARRIAGE BUSHING 43. ANKLE STRAP
(2 PCS)
47. U-BRACKET
(1 PC)
52. CABLE STOP
(4 PCS)
24. LEFT SPOTTER
(2 PCS) (1 PC)
29. UPRIGHT BACKREST
(4 PCS) (1 PC)
33. GUIDE CAP 34. M6 X 20 MM SCREW
(2 PCS) (4 PCS)
39. FULL GUARD
(4 PCS) (4 PCS)
44. 50 MM SPACER
(1 PC) (1 PC)
48. HANDGRIP 49. 50 MM X 75 MM CAP
(2 PCS) (7 PCS)
53. CLIP 54. LONG CABLE
(4 PCS) (1 PC)
7
25. RIGHT SPOTTER
(1 PC)
30. ARM PAD
(2 PCS)
35. BARBELL REST
(2 PCS)
40. HALF GUARD
(22 PCS)
45. 24 MM SPACER
(2 PCS)
50. STABILISER FOOT
(4 PCS)
55. 25 MM SPACER
(14 PCS)
