Pre Assembly Check List - Trojan MULTIFUNTION SMITH MACHINE User Manual

Thank you for choosing the Trojan Multifunction Smith Machine. We take great pride in producing this product
and hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to
its fullest. Yes, it's a proven fact that a regular exercise program can improve your physical and mental health.
Too often, our busy lifestyles limit our time and opportunity to exercise. The Trojan Multifunction Smith
Machine provides a convenient and simple method to begin your assault on getting your body in shape and
achieving a healthier lifestyle. Before reading further, please review the drawing below and familiarise yourself
with the parts that are labelled.
Read this manual carefully before using the Trojan Multifunction Smith Machine.
RIGHT SIDE
Lat Bar
Handle
Weight Bar
Barbell Rest
Upright
Barbell Spotter
Backrest
Curl Pad
Seat
Curl bar
Leg Lever
Note: The terms "right side" and "left side" are determined relative to a person sitting on the bench;
they do not correspond to right and left on the drawings in the manual.
Set-up Size
User Weight
Loading Weight
#21M05T035 Multifunction Smith Machine UM A4.indd 5

PRE ASSEMBLY CHECK LIST

2690 mm (l) x 2110 mm (w) x 2160 mm (h)
200 kg (maximum)
200 kg (maximum)
5
LEFT SIDE
Butterfly Arm
Weight Carriage
Storage Tube
Spotter
Foot Plate
