Trojan MULTIFUNTION SMITH MACHINE User Manual page 12

No. Description
71 Butterfly Cable
72 Low Cable
73 High Cable
74 Pulley Plate
75 Spacer (6 mm)
76 Large Washer (M10)
77 Button Bolt (M10 x 20 mm)
78 Locknut (M8)
79 Locknut (M10)
80 Round Cap (25 mm x 2 mm)
81 Chain
82 Self-tapping Screw (M4 x 19 mm)
83 Carriage Bolt (M10 x 65 mm)
84 Washer (M10)
85 Shoulder Bolt (M8 x 20 mm)
86 Washer (M6)
87 Screw (M6 x 70 mm)
88 Bolt (M10 x 63 mm)
89 Bolt (M10 x 90 mm)
90 Bolt (M10 x 68 mm)
91 Spring Collar
92 Bolt (M10 x 95 mm)
93 Split Washer (M10)
94 Washer (M8)
95 Button Screw (M10 x 30 mm)
96 Bolt (M10 x 45 mm)
97 Bolt (M10 x 93 mm)
98 Screw (M10 x 25 mm)
99 Bolt (M10 x 155 mm)
100 Locknut (M6)
101 Bolt (M10 x 115 mm)
102 Button Bolt (M10 x 75 mm)
103 Large Full Guard
104 Bolt (M10 x 50 mm)
105 Bolt (M10 x 75 mm)
106 Bolt (M10 x 81 mm)
107 Bench Frame
108 Bench Stabiliser
#21M05T035 Multifunction Smith Machine UM A4.indd 12
PARTS LIST
Qty No. Description
1 109 Front Leg
1 110 Leg Lever
1 111 Backrest Bracket
2 112 Curl Bar
6 113 Curl Post
2 114 Curl Pad
4 115 Long Pad Tube
8 116 Seat
74 117 Backrest
2 118 Backrest Frame
1 119 Square Cap (25 mm)
16 120 Cap (20 mm x 40 mm)
10 121 Screw (M6 x 40 mm)
64 122 Seat Frame
2 123 Seat Pin
13 124 Bench Knob
6 125 Curl Cap
2 126 Round Cap (25 mm x 1.5 mm)
7 127 Pad Cover
10 128 Foam Pad
2 129 Pad Tube
2 130 Bolt (M8 x 42 mm)
12 131 Square Cap (63.5 mm x 1.5 mm)
4 132 Square Cap (63.5 mm x 2 mm)
2 133 Square Cap (50 mm)
11 134 Butterfly Bushing
12 135 Leg Bumper
4 136 Curl Post Knob
1 137 Bolt (M10 x 53 mm)
5 138 Thick Round Cap (48 mm)
2 139 Square Cap (57 mm)
6 140 Round Cap (19 mm)
2 142 Curl Bumper
5 142 Curl Pin
2 143 Carriage Bolt (M8 x 76 mm)
1 144 Bolt (M10 x 85 mm)
1 145 Bolt (M10 x 180 mm)
1 146 Screw (M6 x 45 mm)
12
Qty
1
1
1
1
1
1
1
1
1
2
4
1
2
1
1
1
1
2
6
6
2
4
3
1
1
4
1
1
2
3
2
6
1
1
2
2
1
4
