126. 25 MM X 1.5 MM ROUND
CAP (2 PCS)
131. 63.5 MM X 1.5 MM
SQUARE CAP (3 PCS)
136. CURL POST KNOB
(1 PC)
141. CURL BUMPER
(1 PC)
146. M6 X 45 MM SCREW
(4 PCS)
#21M05T035 Multifunction Smith Machine UM A4.indd 10
HARDWARE & TOOLS LIST
127. PAD COVER 128. FOAM PAD
(6 PCS)
132. 63.5 MM X 2 MM 133. 50 MM SQUARE CAP
SQUARE CAP (1 PC)
137. M10 X 53 MM BOLT 138. 48 MM THICK
(2 PCS) ROUND CAP (3 PCS)
142. CURL PIN 143. M8 X 76 MM
(1 PC) CARRIAGE BOLT (2 PCS)
129. PAD TUBE
(6 PCS) (2 PCS)
134. BUTTERFLY BUSHING
(1 PC) (4 PCS)
139. 57 MM SQUARE CAP
(2 PCS)
144. M10 X 85 MM BOLT
(2 PCS)
10
130. M8 X 42 MM BOLT
(4 PCS)
135. LEG BUMPER
(1 PC)
140. 19 MM ROUND CAP
(6 PCS)
145. M10 X 180 MM BOLT
(1 PC)
