Chapter 2: Jumpers and Connectors

Internal Connectors

System Reset Button

Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP3
1 2
Pin Settings
1 GND
2 RESET#
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.

HDD LED Connector

Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP2
1 2
Pin Settings
1 HDD_LED+
2 HDD_LED-
