Chapter 1: Product Introduction
Environment
– IEC 68 2-64
– 2G @ sine, 5~500Hz, 1hr/axis
– 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
▪ Shock
– IEC 68 2-27
– 20g peak acceleration (11 msec. duration)
▪ Temperature
– Operating temperature: with 0.35 m/s air flow: 0°C~50°C
– Storage temperature: -20°C~60°C
▪ Operating humidity: 10%~90% relative humidity, non-condensing limits
to be at 90%
Dimensions
▪ System: 557mm x 336.7mm x 55mm
▪ System weight: 5.8 kg
▪ Package: 650mm x 480mm x 170mm
▪ Package weight: 7.85 kg
Power Supply
▪ 1 x 96W AC/DC lockable adapter included in accessory
▪ Input: 100VAC to 240VAC
▪ Output: DC+12VDC
Certification
▪ CE (EN55035 + EN55032)
▪ FCC Class A (EMI part 15B)
▪ LVD (EN62368-1)
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Operating System Support
▪ Windows 10 64-bit
▪ Linux
