Chapter 2: Jumpers and Connectors

Internal Connectors

LVDS Inverter Connector

Connector type: 1x7 7-pin header JST, 2.5mm pitch
Connector location: INV
7 1
Pin Definition
1 5V
3 12V
5 GND
7 Backlight Enable
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 12V
4 Backlight Control
6 GND

System Reset Header

Connector type: 1x2 2-pin header, 2.54mm pitch
Connector location: RESET
2 1
Pin Definition
1 RESET#
2 GND
