APPENDIX A: GPIO Programming Guide
aPPendIX a: GPIo P
APPENDIX A: GPIO Programming Guide
GPI/O (General Purpose Input/Output) pins are provided for custom system
design. This appendix provides definitions and its default setting for the ten
GPI/O pins in the X200 series. The pin definition is shown in the following
table:
Pin No.
GPI/O mode
PowerOn
Default
1
VCC
2
GND
3
GPO0
HIGH
4
GPO1
HIGH
5
GPO2
HIGH
6
GPO3
HIGH
7
GPI0
8
GPI1
9
GPI2
10
GPI3
Control the GPO 0/1/2/3 level from I/O port A02h bit0 / A02h bit1 / A02h
bit2 / A02h bit3.
The bit is Set/Clear indicated output High/Low
Read GPI 0/1/2/3 Set GPO2X
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
roGrammInG
Address
-
-
-
A02h (Bit0)
A02h (Bit1)
A02h (Bit2)
A02h (Bit3)
A02h (Bit4)
A02h (Bit5)
A02h (Bit6)
A02h (Bit7)
G
uIde
46
XPPC 24-200A User Manual
