Chapter 2: Jumpers and Connectors
Internal Connectors
System Reset Button
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP3
1
2
Pin
Settings
1
GND
2
RESET#
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
HDD LED Connector
Connector type: 1x2 2-pin header, 2.0mm pitch
Connector location: JP2
1
2
Pin
Settings
1
HDD_LED+
2
HDD_LED-
17
XPPC 16-200 User Manual
