Chapter 2: Jumpers and Connectors

Jumpers

LCD Panel Voltage Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: LCD_PWR
1 3
Pin Settings
1-2 On 3.3V
2-3 On 5V
1-2 On: default
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.

Clear CMOS

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: CLRCMOS
1 3
Pin Settings
1-2 On Normal
2-3 On Clear CMOS
1-2 On: default
