Rational iCombi Pro Original Installation Manual page 63

6-2/3 (2 AC 230 V)
6-1/1 E (2 AC 230 V)
6-2/3 (2 AC 240 V)
6-1/1 E (2 AC 240 V)
6-2/3 (1 ph 240 V)
6-1/1 E (1 ph 240 V)
6-2/3 (3 AC 200 V)
6-1/1 E (3 AC 200 V)
6-2/1 E (3 AC 200 V)
10-1/1 E (3 AC 200 V)
10-2/1 E (3 AC 200 V)
20-1/1 E (3 AC 200 V)
20-2/1 E (3 AC 200 V)
6-2/3 (3 ph 208 V)
6-1/1 E (3 ph 208 V)
6-2/1 E (3 ph 208 V)
10-1/1 E (3 ph 208 V)
10-2/1 E (3 ph 208 V)
20-1/1 E (3 ph 208 V)
20-2/1 E (3 ph 208 V)
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
Hz Current
consump-
tion (A)
50/60 23.1
50/60 47
Hz Current
consump-
tion (A)
50/60 24
50/60 48.8
Hz Current
consump-
tion (A)
50/60 24
50/60 45
Hz Current
consump-
tion (A)
50/60 15.9
50/60 29.2
50/60 60
50/60 50.5
50/60 99.9
50/60 99.6
50/60 181.9
Hz Current
consump-
tion (A)
60 15.9
60 30
60 62.2
60 52.5
60 103.8
60 103.3
60 188.5
6 | Electrical connection
Power (kW) Fuse (A)
5.3 25
10.8 50
Power (kW) Fuse (A)
5.7 25
11.7 50
Power (kW) Fuse (A)
5.7 30
10.8 60
Power (kW) Fuse (A)
5.3 16
10.1 32
20.8 63
17.5 63
34.6 100
34.5 100
63 200
Power (kW) Fuse (A)
5.7 20
10.8 35
22.4 70
18.9 60
37.4 125
37.2 125
67.9 200
RCD type
B
B
RCD type
B
B
RCD type
B
B
RCD type
B
B
B
B
B
B
B
RCD type
B
B
B
B
B
B
B
63 / 108
