Aligning The Mobile Oven Rack - Rational iCombi Pro Original Installation Manual

5 | Placement
2. Insert the standalone unit into the foot locks.

5.3.3 Aligning the mobile oven rack

Maximum approach angle of trolley leveling device is exceeded
Risk of burning due to hot liquid and food if the approach angle is too
steep.
Ensure that the approach angle of the trolley leveling device is less than 4
degrees.
Malfunction due to a skewed mobile oven rack
Incorrectly aligning the mobile oven rack may cause the unit to malfunction,
such as during cleaning.
Make sure the mobile oven rack is level inside the unit.
1. Make sure there is 205 mm [8 1/8 inches] of clearance between the upper
edge of the entry frame and the floor. The clearance is required so that the
mobile oven rack can be pushed correctly into the unit.
44 / 108
WARNING
NOTICE
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
