3 | Product description
Unit size 20-1/1 and 20-2/1 GN
The installation connections are on the underside of the unit and go up to the
rear of the unit:
3
4
5
6
1 Water connection
3 Equipotential bonding
5 Safety overflow for drain connec-
tion
7 Only for gas units: gas connection
3.2

Technical data

Protection class
The unit corresponds to spray water protection class IPX5.
Environmental conditions
Do not install the unit at ambient temperatures of below 10 °C [50 °F].
n
Do not operate the unit at ambient temperatures of below 10 °C [50 °F].
n
Install the unit in a facility which is sufficiently ventilated with windows or
n
an extraction hood.
Noise emissions value
The noise emissions value is <65 dB.
14 / 108
7
2 Cable conduit for electrical con-
nection
4 Drain connection
6 Network connection
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
1
2
