Rational iCombi Pro Original Installation Manual page 66

6 | Electrical connection
6-2/1 E (3 AC 480 V)
10-1/1 E (3 AC 480 V)
10-2/1 E (3 AC 480 V)
20-1/1 E (3 AC 480 V)
20-2/1 E (3 AC 480 V)
6-1/1 E (3 ph 480 V)
6-2/1 E (3 ph 480 V)
10-1/1 E (3 ph 480 V)
10-2/1 E (3 ph 480 V)
20-1/1 E (3 ph 480 V)
20-2/1 E (3 ph 480 V)
6-2/3 (3 NAC 400 V)
6-1/1 E (3 NAC 400 V)
6-2/1 E (3 NAC 400 V)
10-1/1 E (3 NAC 400 V)
10-2/1 E (3 NAC 400 V)
20-1/1 E (3 NAC 400 V)
20-2/1 E (3 NAC 400 V)
6-2/3 (3 NAC 415 V)
6-1/1 E (3 NAC 415 V)
6-2/1 E (3 NAC 415 V)
10-1/1 E (3 NAC 415 V)
10-2/1 E (3 NAC 415 V)
20-1/1 E (3 NAC 415 V)
66 / 108
Hz Current
consump-
tion (A)
50/60 26.9
50/60 22.7
50/60 45
50/60 44.7
50/60 81.7
Hz Current
consump-
tion (A)
60 13
60 26.9
60 22.7
60 45
60 44.7
60 81.7
Hz Current
consump-
tion (A)
50/60 9.2
50/60 15.6
50/60 32.3
50/60 27.3
50/60 54
50/60 53.7
50/60 98
Hz Current
consump-
tion (A)
50/60 9.5
50/60 15
50/60 33.7
50/60 28.5
50/60 56.5
50/60 56.2
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
Power (kW) Fuse (A)
22.4 32
18.9 25
37.4 50
37.2 50
67.9 100
Power (kW) Fuse (A)
10.8 20
22.4 35
18.9 30
37.4 60
37.2 60
67.9 100
Power (kW) Fuse (A)
5.7 10
10.8 16
22.4 35
18.9 32
37.4 63
37.2 63
67.9 100
Power (kW) Fuse (A)
6.3 10
10.8 16
24.2 35
20.5 32
40.6 63
40.4 63
RCD type
B
B
B
B
B
RCD type
B
B
B
B
B
B
RCD type
F
F
B
F
B
F
B
RCD type
F
F
B
F
B
F
