9 | Drain connection

9 Drain connection
9.1

Regulations for drain connection

General notes for all units
The drain pipe does not meet requirements
Use a drain pipe with a high temperature resistance, which corresponds at
least to a type PP pipe. Do not use a hose.
Incorrect installation of drain pipe
Do not solvent weld or glue the drain pipe to the unit drain.
Do not connect the drain pipe using a reducer to the unit drain.
Never close or cover the safety overflow
Do not reduce the safety overflow in the cross section.
The safety overflow must always be accessible and free. This is used for
ventilation and drainage as a drain.
Dirty and greasy waste water
Make sure that a grease trap is installed by the owner to clarify the waste
water.
The unit complies with all relevant regulations (SVGW, KIWA, KIWA UK).
n
The average wastewater temperature is 65°C [149°F].
n
When dimensioning the drain, ensure that the steam generator short-term
n
pump-off rate is 0.5 l/s [0.13 gal/s].
If floor drain has no odour lock, make sure a 20 mm [0.79 inch] free outlet
n
section is in place.
Each unit size can be connected to a wall drain or floor drain.
n
Requirements for the unit size 6-2/3 GN
We recommend integrating a siphon into the drain connection in order to op-
timise energy consumption.
Diameter of the unit drain: DN 40 mm [1.5 inches]
n
76 / 108
NOTICE
NOTICE
NOTICE
NOTICE
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
