Rational iCombi Pro Original Installation Manual page 25

Risk of crushing and injury during Combi-Duo installation
There is an increased risk of crushing hands and fingers with Combi-Duo
installations.
The distance between the bars of the lifting aid and the Combi-Duo kit are
extremely small when positioning the unit on the kit.
Ensure that the unit is lowered carefully on to the kit and is stable when
n
positioned on the installation surface.
Place the unit on the installation surface so that there is sufficient space
n
between the kit and the lifting aid to protect hands and fingers.
Correctly mounted lifting aid wobbles without load
If the lifting aid is mounted completely and correctly, a slight movement may
occur in horizontal direction without load.
The screw connection ensures that the lifting aid cannot slip out of the lifting
points. Transportation can take place safely.
Follow the safety instructions in the installation manual.
a
All side panels are closed.
a
The unit is as close as possible to the final installation surface.
a
A torque wrench with suitable attachment is ready.
a
The installation surface, the unit and the lifting aid are clean and grease-free.
a
Appropriate protective clothing is worn, such as protective gloves.
1. Slide the seal upwards from the slot in the base frame.
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
CAUTION
NOTICE
4 | Transport
25 / 108
