6 | Electrical connection
a
The mains lead cleat for the mains cable is tightened.
a
The electrical compartment is open.
1. Connect the wires to the flat pins. Adhere to the following colour coding.
2. Check that the wires are properly plugged in.
>>
The unit is connected to the mains.
Colour coding of flat pins
Connection
Phase
Neutral conductor
Protective conductor
6.7

Close the electrical compartment

Clamped cable
When closing the electrical compartment, make sure that no cables or tubes
are trapped.
Unit size 6-2/3 GN
1. Insert the left side panel underneath the unit frame upwards.
2. Press the side panel upwards.
3. Tighten 2 screws on the underside of the side panel and 1 screw on the
rear side.
>>
The electrical compartment is closed.
Unit size 6-1/1 GN to 10-2/1 GN
1. Insert the left side panel underneath the unit frame upwards.
2. Press the side panel upwards.
3. Press the side panel inwards in the bottom area.
>
The front edge is behind the plastic part and the rear edge is above the
earthing plate.
4. Tighten 2 screws on the rear side of the unit.
5. Put the blind rivet nuts on the front side in the bottom left corner and
tighten them.
6. Insert the grate and press it down.
7. Check that the floor gasket is positioned correctly.
>>
The electrical compartment is closed.
60 / 108
Wire colour
Brown, black or grey
Blue
Yellow/green
NOTICE
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
Flat pin
L1
N
PE
