Only for Japan:
n
The unit must be installed under an exhaust hood.
On-site ventilation
When installing an exhaust device, observe the following:
VDI Directive 2052, NFPA 96 and local construction authority regulations
n
on exhaust hoods.
The exhaust device must protrude 300-500 mm [12 – 20 inches] over the
n
front of the unit.
USA and Canada: The exhaust device must protrude 150-500 mm [6 –
n
20 inches] over the front of the unit.
Install the unit underneath an exhaust device if using a VarioSmoker.
n
Install a fat filter into the protruding part of the exhaust device.
n
Extraction hood
An extraction hood (also for retrofitting) is available for the units. To install the
extraction hood, follow the installation manual supplied with the extraction
hood.
