5 | Placement
2. Insert the stand into the foot locks.
Mobile stand
Align mobile stand
To counter any bumps in the ground and to align the mobile stand, proceed as
follows:
1. Loosen the headless screws on the castors with an Allen key.
2. Adjust the height to the castors with a screw wrench until the castors are
secure.
3. Secure the grub screw to the castors with a hexagon socket wrench.
Attach the mobile base frame
Damage to electrical or gas lines due to shifting
Also secure the unit with a suitable retention unit to prevent it from
slipping on the rear wall (retention units are not included in the scope of
delivery).

5.2.4 Installation on non-original substructures of the unit manufacturer

Risk of crushing due to the weight of the unit
Hands, fingers and feet can be crushed.
Use appropriate protective clothing during transport.
n
Risk of injury due to inadequate substructure
Setting up the unit on statically inadequate substructures can result in injury
and damage to the unit and substructure.
38 / 108
NOTICE
CAUTION
CAUTION
80.06.070_iCombiPro-iCombiClassic_IM_en-GB
