Technical Data - Rational iCombi Pro Original Installation Instructions

3 | Product description
Unit size 20 half size and 20 full size GN
The connections for the installation are located on the underside of the unit
and run to the rear:
3
4
5
6
1 Water connection
3 Equipotential bonding (Earth
ground)
5 Safety overflow for wastewater
connection
7 Only for gas units: gas connection
3.2

Technical data

Protection class
The unit corresponds to water jet connection class IPX5.
Ambient conditions
Do not set up the unit in ambient temperatures below 10 °C [50 °F].
n
Do not commission the unit in ambient temperatures below 10 °C [50 °F].
n
Set up the unit in rooms with adequate ventilation via windows or an ex-
n
tractor hood.
Sound emission value
The sound emission value is <65 dB.
14 / 100
7
2 Cable bushing for electrical con-
nection
4 Drain connection
6 Network connection
80.06.083_iCombiPro-iCombiClassic_IM_en-US
1
2
