1.2

Features


SMARC interface MXM3 connector
 PCI Express Bus

3x PCIe x1 links
 1x PCIE x1 slot

2x PCIE Mini slots
 Serial Port UART interfaces (4x UART)
 Null Modem RS-232 on serial ports COM0 - COM3
 2-wire and 4-wire connectors
 COM0 - COM3 interfaces on four 9-pin, DB9 connectors

USB interfaces
 One USB, 4-connector stack for ports 5 through 8 (USB 2.0)

One USB single connector for ports 0 and 1 (USB 3.0/2.0)
 One mini-USB for USB 2.0 OTG or client

Gigabit Ethernet interface
 One standard RJ-45 connector

Activity/Link and Speed LED on Ethernet connector
 SDIO interface

One SDIO slot, 4-bit (for SD card)
 SDMMC interface

One SDMMC board-to-board connector, 8-bit (for eMMC)
 Audio interfaces

Supports HD Audio and AC'97
 One 3-in-1 stack audio jack for I2S audio with Line In / Line Out / MIC In
 One 3-in-1 stack audio jack for HD audio with Line In / Line Out / MIC In
 One 4-pin, SPDIF Input / Output header
 One I2S audio header

Video interfaces
 One HDMI connector for HDMI A interface

One Display Port connector
 One HDMI or Display Port connector for HDMI B or Display Port interface

One single-channel LVDS header (dual channel optional)
 One LCD RGB header (HDMI/DP/LVDS CH B optional)

One LVDS backlight header
 One LCD RGB backlight header

Power interface
 One ATX-2.2 Power In connector (+12V and +5V)

Interface voltages are generated on the carrier (+3.3V, +2.8V, +1.8V, and +1.5V)
 Optional: BattMan power supply
