Table 2-1: Header, Switch, LED, and Connector Descriptions (Continued)
CN73 PCie2 Mini, Latch
CN74 PCie2 Mini, Latch
CN75 PCie2 Mini, Latch
CN76 PCie2 Mini, Latch
CN77 USB 2.0 / 3.0, Ports 1 / 0 9-pin standard, right-angle Type A, USB connector for USB 2.0
CN78 GbE, Standard RJ45
CN79 HDMI A, Standard
CN80 Camera, PCAM / CSI
CN81 PWR Bad Enable
CN82 Voltage Select for
BattMan SMBus
CN83 HDMI B, Standard
CN84 Display Port, Standard
CN85 Display Mode Select, DP
/ HDMI
CN86 SATA1, Standard
LED1 SATA Activity
LED2 Watchdog Activity
LED3 Carrier Power
LED4 Module Power
LED5 SD Power
SW1 Power On
SW2 Reset
SW3 Sleep
SW5 Start Debian Installer
SW6 DP Control
10
Latch for fastening PCI Express Mini card
[Attend, 119A-LATCH-80]
Latch for fastening PCI Express Mini card
[Attend, 119A-LATCH-80]
Latch for fastening PCI Express Mini card
[Attend, 119A-LATCH-80]
Latch for fastening PCI Express Mini card
[Attend, 119A-LATCH-80]
(port1) and USB 3.0 (port0) signals
[FOXCONN, UEA11123-4HK3-4H]
16-pin standard, RJ45 connector with transformer and LED for
Gigabit Ethernet
[UDE, RT7-174AAM1A, BLACK]
19-pin standard, right-angle Type A, connector for HDMI A
signals
[TechBest, HDMI-KRPS00-A30N2A-L-R]
60-pin, 0.5mm board-to-board connector for parallel and CSI
camera signals
[SAMTEC, QSH-030-01-L-D-A, BLACK]
3-pin, 2.0mm jumper header for selecting the source of
VIN_PWR_BAD#
[JIH21N12050-03S10B-01G-4/2.8-G]
3-pin, 2.0mm jumper header for selecting I2C_PM, BattMan
SMBus voltages
[JIH21N12050-03S10B-01G-4/2.8-G]
19-pin standard, right-angle Type A, connector for HDMI B
signals
[TechBest, HDMI-KRPS00-A30N2A-L-R]
20-pin standard, right-angle connector for Display Port signals
[FOXCONN, 3VD51203-D7JJ-7H, BLACK]
3-pin, 2.0mm jumper header for selecting between HDMI B
and DP display mode [JIH21N12050-03S10B-01G-4/2.8-G]
7-pin, standard Serial ATA 1 connector
[WIN WIN, WATM-07ABN4B3B8UW4, Blue]
Yellow LED indicating SATA activity
Red LED indicating Watchdog activity
Green LED indicating carrier power
Green LED indicating module power
Green LED indicating SD power
Push-button switch to Power On or shut down the module
[CONTACT, TS-A02-2, BLACK]
Push-button switch to warm reset the module
[CONTACT, TS-A02-2, BLACK]
Push-button switch to induce module sleep mode
[CONTACT, TS-A02-2, BLACK]
Push-button switch for Automatically starting Linux installer on
ARM CPU
[CONTACT, TS-A02-2, BLACK]
4-pole, 1.27mm dip switch for Display Port control
[DIPTRONICS, DHNF-04-T-Q-T/R]
Note: Refer to the PI3EQXDP1201, Display Port Redriver data
sheet for more details.
