Camera interface
 One PCAM / MIPI CSI high-density connector
 Two serial cameras
 One parallel camera
 Mixed mode (serial / parallel)
 Fan interfaces
 One fan power selection (12V or 5V) jumper header
 One fan function header
 SATA interfaces
 Two standard SATA3 connectors (SATA0 and SATA1)
 SATA1 can be optionally connected to the AFB port
2

I C interface
 One general purpose I
2
 One I C camera
2

One I C LCD display I/D

CAN interface

Two CAN DB9 connectors

SPI interfaces

Two SPI headers

Miscellaneous

Twelve GPIOs (interrupt capable)

Watchdog

Smart Battery
 AFB (Alternate Function Block)
 RTC
 PWM Buttons
 Boot Select
1.3

Ordering Information

Model Number
LEC-BASE MINI Standard
(91-77A03-000E or higher)
LEC-BASE MINI Custom
(91-77A03-010E or higher)
Product Overview
2
C header
Table 1-1: LEC-BASE MINI Models
Second generation SMARC evaluation carrier with triple display
(RGB LCD, SC LVDS and HDMI). This version is the standard config-
uration of the carrier, which is fully compliant with SMARC specifica-
tion 1.1. This standard version supports one RGB LCD display, one
single channel LVDS (18/24 bit) display, and one HDMI display.
Second generation SMARC evaluation carrier with triple display (DC
LVDS, HDMI, and HDMI/DP). This version is a custom option, if a
third digital display is needed. This custom version supports one dual
channel LVDS (18/24 bit) display, one HDMI display, and one
HDMI/DP display.
Description
LEC-BASE MINI
