Table 2-1: Header, Switch, LED, and Connector Descriptions (Continued)
CN22 SPDIF I/O (CODEC)
CN25 LVDS
CN26 LVDS Voltage Select
CN27 LVDS Backlight
CN28 CAN
CN29 CAN0 Termination
CN30 CAN1 Termination
CN31 SPI 0
CN32 SPI 1
CN33 COM0 [top] / COM2
[bottom]
CN34 COM1 [top] / COM3
[bottom]
CN35 GPIO 0-3
CN37 AFB
CN39 GPIO 4-7
CN41 GPIO 8-11
CN43 Miscellaneous
CN44 I2S1
CN45 Smart Battery
CN46 Battery Enable
CN48 Boot Select 0
CN49 Boot Select 1
CN50 Boot Select 2
CN51 Boot Select Force
Recovery
8
4-pin, 2mm header for SPDIF digital audio interface from the
carrier CODEC
[SAMTEC, TMM-102-01-T-D-SM]
34-pin, 2mm header for LVDS output
[JIHVEI, 23N6850-34S10B-01G-G, BLACK]
6-pin, 2mm jumper header for selecting display and backlight
LVDS voltages
[JIHVEI, 27S1001-OPS35-01G-B, BLACK]
8-pin, 2.54mm shrouded header for LVDS backlight control
[JIHVEI, 23N6960-08S10B-01G-G, BLACK]
9-pin, standard dual DB9 connectors for transmitting and
receiving Controller Area Network signals
[FOXCONN, DM10151-H531-4F, TEAL]
2-pin, 2mm jumper header to terminate CAN0 interface
[JIH, 21N12050-02S10B-01G-4/2.8-G]
2-pin, 2mm jumper header to terminate CAN1 interface
[JIH, 21N12050-02S10B-01G-4/2.8-G]
10-pin, 2.54mm header for SPI0 (Serial Peripheral Interface)
signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
10-pin, 2.54mm header for SPI1 (Serial Peripheral Interface)
signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
9-pin standard, dual DB9 connectors for RS232 serial ports
with 4-wire, RX/TX and RTS/CTS support
[AMPHENOL, G17H1110131EU]
9-pin standard, dual DB9 connectors for RS232 serial ports
with 2-wire, RX/TX support
[AMPHENOL, G17H1110131EU]
10-pin, 2.54mm header for GPIO 0-3 signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
34-pin, 2.54mm AFB (Alternate Function Block) for optionally
connecting USB 3.0, SATA1, or general purpose AFB signals
[JIHVEI, 23N6850-34S10B-01G-G, BLACK]
10-pin, 2.54mm header for GPIO 4-7 signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
10-pin, 2.54mm header for GPIO 8-11 signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
10-pin, 2.54mm header for miscellaneous power signals
[JVE, 21N22564-10M00B-01G-6, BLACK]
8-pin, 2.54mm shrouded header for I2S1 signals
[JIHVEI, 23N6960-08S10B-01G-G, BLACK]
10-pin, 2.54 box header for BattMan signals
[JIHVEI, 23N6960-10S10B-01G-G, BLACK]
2-pin, 2.0mm jumper header to enable RTC coin cell battery
[JIH JVE, 27S1001-OPS35-01G-B, BLACK]
3-pin, 2.54mm jumper header for boot select signals
[NELTRON,2317SJ-06, WHITE
3-pin, 2.54mm jumper header for boot select signals
[NELTRON,2317SJ-06, WHITE
3-pin, 2.54mm jumper header for boot select signals
[NELTRON,2317SJ-06, WHITE
3-pin, 2.54mm jumper header for boot select, force recovery
signals
[NELTRON,2317SJ-06, WHITE]
