3.33 LIN_L Codec Select (CN62)

Table 3-40 lists the pin signals of the LIN_L Codec Select jumper header, which provides 3 pins
in a single row with 2.00mm pitch.
Pin #
1 LIN_L_C1
2 LIN_L_FIL
3 LIN_L_C2

3.34 LIN_R Codec Select (CN63)

Table 3-41 lists the pin signals of the LIN_R Codec Select jumper header, which provides 3 pins
in a single row with 2.00mm pitch.
Pin #
1 LIN_R_C1
2 LIN_R_FIL
3 LIN_R_C2

3.35 LOUT_L Codec Select (CN64)

Table 3-42 lists the pin signals of the LOUT_L Codec Select jumper header, which provides 3
pins in a single row with 2.00mm pitch.
Pin #
1 LOUT_L_C1
2 LOUT_L_FIL
3 LOUT_L_C2

3.36 LOUT_R Codec Select (CN65)

Table 3-43 lists the pin signals of the LOUT_R Codec Select jumper header, which provides 3
pins in a single row with 2.00mm pitch.
Pin #
1 LOUT_R_C1
2 LOUT_R_FIL
3 LOUT_R_C2
Interfaces
Table 3-40: LIN_L Codec Select (CN62)
Signal
• Jumper Installed 1-2 - CODEC SGTL5000 (Default)
• Jumper Installed 2-3 - CODEC AIC3106
Table 3-41: LIN_R Codec Select (CN63)
Signal
• Jumper Installed 1-2 - CODEC SGTL5000 (Default)
• Jumper Installed 2-3 - CODEC AIC3106
Table 3-42: LOUT_L Codec Select (CN64)
Signal
• Jumper Installed 1-2 - CODEC SGTL5000 (Default)
• Jumper Installed 2-3 - CODEC AIC3106
Table 3-43: LOUT_R Codec Select (CN65)
Signal
• Jumper Installed 1-2 - CODEC SGTL5000 (Default)
• Jumper Installed 2-3 - CODEC AIC3106
Jumper Position
Jumper Position
Jumper Position
Jumper Position
